1455CF1201BK
120 × 54 × 23 mm
Material: Aluminium
Category: All Products, Diecast & Metal
Extruded Enclosure with Side Mounting Flange, 120x54x23, Black Anodise
£10.97
Add to QuoteAsk a QuestionReport an Error
Enclosure Customisation
CNC Holes, Slots, Shapes, Routing, Custom Colours, Printing and Assembly Kits are available for this product.
Manufacturing
PCB Assembly, Wiring, Keypads & Components right up to a full Turnkey Box-Build.
Product Details
Key Features:
- Designed to house P.C. boards or for equipment interfacing.
- Integrated slotted flanges allow for easy Wall Mounting.
- Flange provides a completely flat bottom surface and transitions seamlessly into the extrusion body for a finished look.
- Sized for 50mm wide PC boards.
- P.C. boards mount into extrusions by sliding into internal slots extruded into the enclosure body.
- Rugged body constructed from extruded aluminium with a minimum thickness of .06? (1.5 mm).
Includes:
- Extruded aluminium body – choice of clear or black anodized.
- (2) aluminium end panels.
- Includes all hardware – end panel screws are zinc-plated #6 x 3/8? TTT thread rolling, steel screws with a #4 flat head phillips drive. Supplied screws are natural or black to match housing.
- Replacement end panels available in packs of 10 (see table below).
- For black replacement screws (quantity 100) order part number 1455MS100BK.
- For clear replacement screws (quantity 100) order part number 1455MS100.
- NOTE: Recommended screw torque is 5 lbf-in.
Don’t need Wall Mounting flanges?? Try our standard 1455 Series.
Photo Features:
Unassembled
Clear anodized version
Black anodized version
Completely flat bottom for seamless Wall Mounting.
Technical
| Dimensions | 120 × 54 × 23 mm |
|---|---|
| Colour | Black |
| Height | 23 |
| Width | 54 |
| Length | 120 |
| IP Rating | IP54 |
| Manufacturer | Hammond |
| Material | Aluminium |
| Flammability | N/A |
| Shape | Rectangular/Square |
| Mounting | Wall Mount |
| Feature | N/A |
| Series | 1455F |
