1557H2BK-2
1.1 MB
Enclosure Solutions operates a continuous improvement policy. The information contained on this site is provided on an ‘as-is’ basis with no guarantees of completeness, accuracy or usefulness.Errors and omissions excepted.
SCROLL DOWN FOR TECHNICAL INFORMATION
ACCESSORIES AVAILABLE UPON REQUEST
1557H2BK
200 × 200 × 45 mm
Material: Polycarbonate
Category: All Products, General Purpose Plastic
Waterproof PC Wallmount Enclosure, 200 x 200 x 45
£28.53
Add to QuoteAsk a QuestionReport an Error
Enclosure Customisation
CNC Holes, Slots, Shapes, Routing, Custom Colours, Printing and Assembly Kits are available for this product.
Manufacturing
PCB Assembly, Wiring, Keypads & Components right up to a full Turnkey Box-Build.
Product Details
Key Features:
- Ideally suited for mounting printed circuit boards.
- Can be used in a tabletop configuration or two different Wall Mount configurations.
- Rounded corners and face provide a more modern look while still offering superior water-tight ratings.
- Available in black or grey ABS plastic or UL listed polycarbonate
- ABS versions are moulded from general purpose material which carries a flammability rating of UL94-HB. ?For indoor use.
- Polycarbonate versions are UV stabilized for outdoor use and carry a UL94-5VA flammability rating.? For indoor or outdoor use.
- Polycarbonate versions are UL and UL 508A listed (File # E65324), NEMA 4, 4X, 6, 6P. ?ABS plastic versions are not UL listed.
- Gasketed lid with two piece ?tongue & groove? construction provides protection against access of oil, dust and water.
- Gasket is one piece made from high temperature, U.L. listed silicone.
- ABS versions are designed to meet IP66
- Polycarbonate versions are designed to meet IP68
- Lid is secured with included M4 stainless steel machine screws which are threaded into corrosion resistant bushings for repetitive assembly & disassembly. All hardware is designed to avoid corrosion caused by harsh environments over time.
- Aluminium inner panels are available as accessories.? Sold separately.? See table below.
Heavy Duty Wall Flange Mount (Mounting Feet Outward)
Flush Wall Mount (Mounting Feet as Keyhole Slots)
Desktop / Tabletop (Rubber Feet Included)
Technical
| Dimensions | 200 × 200 × 45 mm |
|---|---|
| Colour | Black |
| Height | 45 |
| Width | 200 |
| Length | 200 |
| IP Rating | IP68 |
| Manufacturer | Hammond |
| Material | Polycarbonate |
| Flammability | UL94-5VA |
| Shape | Rectangular/Square, Rounded Design |
| Mounting | Free Standing, Pole Mount, Wall Mount |
| Feature | N/A |
| Series | 1557 |
