2955 Series Buttoned Keyfob Enclosure_D
338.57 KB
Enclosure Solutions operates a continuous improvement policy. The information contained on this site is provided on an ‘as-is’ basis with no guarantees of completeness, accuracy or usefulness.Errors and omissions excepted.
SCROLL DOWN FOR TECHNICAL INFORMATION
ACCESSORIES AVAILABLE UPON REQUEST
2955-20R-3
57 × 35 × 12 mm
Material: ABS
Category: All Products, Hand-Held
20 Series Round Keyfob Enclosure with Buttons
£3.39
Add to QuoteAsk a QuestionReport an Error
Enclosure Customisation
CNC Holes, Slots, Shapes, Routing, Custom Colours, Printing and Assembly Kits are available for this product.
Manufacturing
PCB Assembly, Wiring, Keypads & Components right up to a full Turnkey Box-Build.
Product Details
2955-20R-3 – 2955-20 Series Round Keyfob Enclosure with Buttons
2955-20 Series Round Keyfob Enclosure, Black, 57x35x12, 3 Button
Moulded in ABS
Snap-fit assembly of lid and base
1 to 5 ergonomically shaped rubber buttons with contact pads
Base incorporates a separate enclosed battery compartment for coin cells
Eyelet for key-ring
Technical
| Dimensions | 57 × 35 × 12 mm |
|---|---|
| Colour | Black |
| Height | 12 |
| Width | 35 |
| Length | 57 |
| IP Rating | IP54 |
| Manufacturer | CamdenBoss |
| Material | ABS |
| Flammability | UL94-V1 |
| Shape | Keyfob, Rectangular/Square, Rounded Design |
| Mounting | Hand-Held |
| Feature | Battery Compartment, Easy Assembly |
| Series | 2955 |
Downloads
2955-20R-3
1.52 MB
